Application: suitable in high fire risk places containing a great number of people where low emissions of smoke and acid gases is required.
Conductor: Plain annealed flexible copper, class 5
Sheath: LSZH (Low smoke zero halogen)
Operating temperature: Maximum 90°C, Minimum bending -15°C
Application: suitable in high fire risk places containing a great number of people
where low emissions of smoke and acid gases is required.
Conductor: Plain annealed flexible copper, class 5
Sheath: LSZH (Low smoke zero halogen)
Operating temperature: Maximum 90°C, Minimum bending -15°C
| Size | 0.75mm, 1mm, 1.5mm, 2.5mm, 4.0mm, 6.0mm, 10mm, 16mm, 25mm |
|---|---|
| Colour | Black, Blue, Brown, Green/Yellow, Red, White, Yellow, Grey, Green, Violet |
| Meters | 100 |
UL1007 Wires are designed and manufactured for the use of switch ,control metering, instrumentation panels and connections to motor starters and controllers. Conforming to UL1007 style cables are 300V and 80 degrees rated and carry UL Approvals.
Tri-Rated Cables To CSA Type TEW, UL Type AWM Style 1015 (Incl. 1028, 1283 and 1284) and BS 6231
Flexible Class 5 High Temperature flame-retardant single core, rated voltage 600V AC / 1000V DC .
Steel Wire Armoured – BS6724 SWA LSOH BASEC 0.6/1kV Cable Stranded plain annealed copper conductors, XLPE insulated, LSOH bedding, galvanized steel wire armor, LSOH outer sheath. Black. 600/1000 volts grade to BS6724.
