Description
Belden Cable ® 3082A
DeviceNet cable 15 and 18 AWG stranded tinned copper conductors, PVC insulation (power), FPE insulation (data), individually foil shielded (100% coverage) plus an overall tinned copper braid (65% coverage), sunlight/oil-resistant PVC jacket.
Belden Cable ® 3084A
DeviceNet Cable 22 and 24 AWG stranded tinned copper conductors, PVC insulation (power), FPE insulation (Data), individually foil shielded (100% coverage) and an overall tinned copper braid (65% coverage), sunlight/oil-resistant PVC jacket.
Belden Cable ® 8723
22 AWG stranded (7×30) tinned copper conductors, polypropylene insulation, twisted pairs, individually Beldfoil® shielded (100% coverage), 24 AWG stranded tinned copper drain wire, PVC jacket.
Belden Cable ® 8728
Multi-Conductor Special Audio,Communication and Instrumentation Cable 22 AWG stranded (7×30) TC conductors, polypropylene insulation, cabled in pairs, overall Beldfoil® shield (100% coverage), 24 AWG stranded TC drain wires, PVC jacket.
Belden Cable ® 8760
18 AWG stranded (16×30) tinned copper conductors, polyethylene insulation, twisted pair, overall Beldfoil ®shielded (100% coverage), 20AWG stranded tinned copper drain wire, PVC jacket
Belden Cable ® 8761
Multi Conductor Single Pair Cable – 22 AWG stranded (7×30) TC conductors, polyethylene insulation, twisted pair, overall Beldfoil® shield (100% coverage), 22 AWG stranded TC drain wire, PVC jacket
Belden Cable ® 8776
Multi Conductor CM-Rated Cable-22 AWG stranded (7×30) tinned copper conductors , polypropylene insulation, twisted pairs individually Beldfoil® Shielded ( 100% coverage),overall PVC jacket 22 AWG stranded tinned copper drain wire.
Belden Cable ® 8777
22 AWG stranded (7×30) tinned copper conductors , polypropylene insulation, twisted pairs individually Beldfoil® Shielded ( 100% coverage), 22 AWG stranded tinned copper drain wire, PVC jacket
Belden Cable ® 8778
Multi conductor-CM rated cable- 22 AWG stranded (7×30) tiinned copper conductor, polyproplene insulation, twisted pairs individually shielded with Beldfoil®(100% coverage), overall PVC jacket and 22AWG stranded copper drain wire.
Belden Cable ® 9272
Twinax-Twinaxial Cable – 20 AWG stranded (7×28).0.38″ tinned copper conductors, polyethylene insulation, tinned copper braid shield (93% coverage), PVC jacket.
Belden Cable ® 9463
Twinax- Blue Hose® Cable- 20 AWG stranded (7×28).038″ tinned copper conductors,polyethylene insulation, Beldfoil® (100% coverage) plus a tinned copper braid shield (55% coverage) , sunlight-resistant PVC jacket.
Belden Cable ® 9501
Multi-Conductor- 1 Pair Computer Cable for EIA RS-232 Applications- 24AWG stranded (7×32) TC conductors, semi-rigid PVC insulation, twisted pairs, overall Beldfoil® shield (100% coverage), 24 AWG stranded TC drain Wire, PVC jacket.
Belden Cable ® 9502
Multi-Conductor- 2 Pair Computer Cable for EIA RS-232 Applications- 24AWG stranded(7×32) TC conductors, semi rigid PVC insulation, twisted pairs, overall Beldfoil® shield (100% coverage), 24AWG stranded TC drain wire, PVC jacket.
Belden Cable ® 9503
Multi-Conductor – 3 Pair Computer Cable for EIA RS-232 Applications- 24 AWG stranded(7×32) TC conductors, semi rigid PVC insulation , twisted pairs, overall Beldfoil® shield (100% coverage), 24 AWG stranded TC drain wire, PVC jacket.
Belden Cable ® 9504
Multi-Conductor – 4 Pair Computer Cable for EIA RS-232 Applications- 24AWG stranded(7×32) TC conductors, semi rigid PVC insulation, twisted pairs , overall Beldfoil® shield (100% coverage) , 24 AWG stranded TC drain wire, PVC jacket.
Belden Cable ® 9506
Multi-Conductor – 6 Pair Computer Cable for EIA RS-232 Applications- 24AWG stranded (7×32) TC conductors, semi rigid PVC insulations, twisted pairs, overall Beldfoil® shield (100% coverage) , 24 AWG stranded TC drain wire, PVC jacket.
Belden Cable ® 9508
Multi-Conductor – 8 Pair Computer Cable for EIA RS-232 Applications – 24AWG stranded (7×32) TC conductors, semi rigid PVC insulation , twisted pairs, overall Beldfoil® shield (100% coverage) , 24AWG stranded TC drain wire, PVC jacket.
Belden Cable ® 9510
Multi-Conductor- 10 Pair Computer Cable for EIA RS-232 Applications- 24 AWG stranded (7×32) TC conductors, semi rigid PVC insulation , twisted pairs, overall Beldfoil® shield (100% coverage), 24 AWG stranded TC drain wire, PVC jacket.
Belden Cable ® 9536
Multi-Conductor – Computer Cable for EIA RS-232 applications- 24 AWG stranded (7×32) tinned copper conductors, conductors cabled, semi-rigid PVC insulation, overall Beldfoil® shield (100% coverage) , 24AWG stranded tinned copper drain wire, PVC jacket.
Belden Cable ® 9538
Multi-Conductor- Computer Cable for EIA RS-232 Appliactions- 24AWG stranded (7×32) tinned copper conductors, conductors cabled , semi-rigid PVC insulation, overall Beldfoil® shield (100% coverage) , 24 AWG stranded tinned copper drain wire, PVC jacket.
Belden Cable ® 9540
Multi-Conductor-Computer Cable for EIA RS-232 applications- 24 AWG stranded (7×32) tinned copper conductors,conductors cabled, semi-rigid PVC insulation, overall Beldfoil® shield (100% coverage), 24AWG stranded tinned copper drain wire, PVC jacket.
Belden Cable ® 9841
Multi-Conductor-Low Capacitance Computer Cable for EIA RS-485 Applications- 24AWG stranded(7×32) TC conductors, polyethylene insulation, twisted pairs, overall Beldfoil® (100% coverage) + TC braid shield (90% coverage) , 24 AWG stranded TC drain wire, PVC jacket.
Belden Cable ® 9842
Multi Conductor – Low Capacitance Computer Cable for EIA RS-485 Applications- 24 AWG stranded (7×32) TC conductors, polyethylene insulation, twisted pairs, overall Beldfoil® (100% coverage) + TC braid shield (90% Coverage), 24 AWG stranded TC drain wire, PVC jacket.
Belden Cable ® 9903
Multi-Conductor – 10Base 5 transceiver Cable- 28AWG & 24AWG stranded TC conductors, non plenum, Polypropylene insulation, twisted pairs,overall polyester isolation tape+ Duofoil®+ TC braid shield (92% coverage), drain wire, light grey PVC jacket.
Belden Cable ® 9913
Coax -RG-8/U Type Cable- 10AWG Solid.108″ bare copper conductor,semi-solid polyethylene, Duobond II ® + tinned copper braid shield (90% coverage) , PVC jacket.
