Bus Cables

Bus Cables , Devicenet Thick & Thin , Profibus, Profibus DP, Interbus , Profinet , Can open bus, industrial Ethernet cables from Contact Cables Ltd.

Full Ranges of Bus Cables can be found HERE

Category:
Click to request data sheet

Description

Unidrall Bus Cable 1000F  -UL/cUL/Ce/ Desina Approved – UL21179 – 1000V -5°/+80°C – Poly / PVC – Profibus Cables

These Unidrall Bus 1000F cables are suitable for Profibus systems in a static application only .The cables are UL/cUL/Ce and Desina approved

Unidrall Bus Cable 1000 -UL/cUL/Ce/ Desina Approved – UL21179 – 1000V -5°/+80°C – Poly / PVC – Profibus Cables

These Unidrall Bus 1000F cables are suitable for Profibus systems in a Mild flexing application only .The cables are UL/cUL/Ce and Desina approved

Unidrall Bus Cable 1000M  -UL/cUL/Ce/ Desina Approved – UL21179 – 1000V -30°/+80°C – Poly / PUR – Profibus Cables

These Unidrall Bus 1000M cables are suitable for Profibus systems in Dynamic high flex drag chain applications offering high performance , notch & chemical resistance due to the PUR sheath material .The cables are UL/cUL/Ce and Desina approved.

Unidrall Bus Cable 1010F-UL/cUL/Ce/ – UL21179 – 1000V -5°/+80°C – Poly / PVC – Interbus Cables

These Unidrall Bus 1010F cables are suitable for Interbus remote Bus 2- Wire systems in a fixed application only , The cables are UL/cUL/Ce approved

Unidrall Bus Cable 1010M -UL/cUL/Ce/ – UL21576 – 1000V -5°/+80°C – Poly / PUR – Interbus Cables

These Unidrall Bus 1010M cables are suitable for Interbus remote Bus 2- Wire systems in a Dynamic high flex drag chain application The cables are UL/cUL/Ce approved

Unidrall Bus Cable 1010S -UL/cUL/Ce/ – UL21576 – 1000V -5°/+80°C – TPE-E / PUR – Interbus Cables

These Unidrall Bus 1010S cables are suitable for Interbus dta transmission/ sensor supply in a Dynamic high flex drag chain application The cables are UL/cUL/Ce approved

Unidrall Bus Cable  1020F -UL/cUL/Ce/ Desina Approved- UL21179 – 1000V -5°/+80°C – POLY / PVC -DeviceNet Cables

These Unidrall Bus 1020F cables are suitable for DeviceNet installations and cover DeviceNet Trunk/Thick and DeviceNet Thin/Drop in fixed applications only , The cables are UL/cUL/Ce & Desina approved

Unidrall Bus Cable 1020M -UL/cUL/Ce/ Desina Approved- UL21179 – 1000V -30°/+80°C – POLY / PUR -DeviceNet Cables

These Unidrall Bus 1020M cables are suitable for DeviceNet installations and cover DeviceNet Trunk/Thick and DeviceNet Thin/Drop in Dynamic high flex drag chain applications, The cables are UL/cUL/Ce & Desina approved and offer enhanced cable performance over the 1020F version due to the PUR sheath.

Unidrall Bus Cable  1030F -UL/cUL/Ce/ Desina Approved- UL21179 – 1000V -5°/+80°C – POLY / PVC -CAN Open Cables

These Unidrall Bus 1030F cables are suitable for CAN ( Control Area Network) and CAN open cable applcations and are based upon ISO11898 standards series . Cables are designed for Fixed applications only , t?he cables are UL/cUL/Ce & Desina approved

Unidrall Bus Cable 1030M -UL/cUL/Ce/ Desina Approved- UL21576 – 1000V -30°/+80°C – POLY / PUR -CAN Open Cables

These Unidrall Bus 1030M cables are suitable for CAN ( Control Area Network) and CAN open cable applcations and are based upon ISO11898 standards series . Cables are designed for Dynamic high flex drag chain applications ,t?he cables are UL/cUL/Ce & Desina approved and due to the PUR sheath material offer enhanced performance over the Unidrall Bus 1030F version.

Unidrall Bus Cable 1040F -UL/cUL/Ce/ – UL21179 – 1000V -5°/+80°C – POLY / PVC – Industrial Ethernet Cables

These Unidrall Bus 1040F cables are suitable for Ethernet american standard EIA/TIA 568B ( Cat 5E) and european standards EN50288 series. Suitable to meet FAST ETHERNET requirements for but rates up to 100 Mbit/s. Cables are designed for Fixed applications only , the cables are UL/cUL/Ce approved.

Unidrall Bus Cable 1040M -UL/cUL/Ce/ – UL21576 – 1000V -30°/+80°C – POLY / PUR – Industrial Ethernet Cables

These Unidrall Bus 1040F cables are suitable for Ethernet american standard EIA/TIA 568B ( Cat 5E) and european standards EN50288 series. Suitable to meet FAST ETHERNET requirements for but rates up to 100 Mbit/s. Cables are designed for Dynamic high flex drag chain applications , the cables are UL/cUL/Ce approved and offer enhanced performance over the PVC Unidrall Bus 1040F version of this cable.

Unidrall Bus Cable 1050F -UL/cUL/Ce/ – UL21179 – 1000V -5°/+80°C – POLY-TPE / PVC – Profinet Cables

These Unidrall Bus 1050F cables are suitable for Profinet Bus systems . Cables are designed for Fixed / low flexing applications only, the cables are UL/cUL/Ce approved.

Unidrall Bus Cable  1050M -UL/cUL/Ce/ – UL21576 – 1000V -30°/+80°C – POLY-TPE / PUR – Profinet Cables

These Unidrall Bus 1050F cables are suitable for Profinet Bus systems . Cables are designed for Dynamic high felx drag chain applications,t?he cables are UL/cUL/Ce approved and due to their PUR sheath offer enhanced performance over the Unidrall Bus 1050F version of this cable.
