Control Flex Cables

Our page for the Range of Control Flex Cables has now moved HERE

Category:
Click to request data sheet

Description

Un-Screened Cables

YY Control Cables -KU500 – PVC / PVC – Number Coded Cores

These Cables are suitable for flexible use in applications of medium mechanical stresses with free movement, without tensile stress or forced movement in dry & moist conditions but not suitable for open air. Used as measuring and control cables in tool machines, conveyor belts, production lines, machinery production and in air conditioning

YY Control Cables -Uniatox 800 – LSZH/ LSZH – Number Coded Cores

These Cables are suitable for flexible use in applications of medium mechanical stresses with free movement, without tensile stress or forced movement and where a requirement for Low Smoke Zero Halogen is required. Conforming to IEC 60332-3C CEI 20-37/2-1 , CEI 20-37/4-0, CEI 20-37/3-1 IEC61034-1, IEC61034-2 , CEI 20-37/2-2, IEC60754-2

YY Control Cables -KU300 – PVC / PVC – Colour Coded Cores

These Cables are suitable for flexible use in applications of medium mechanical stresses with free movement, without tensile stress or forced movement in dry & moist conditions but not suitable for open air. Used as measuring and control cables in tool machines, conveyor belts, production lines, machinery production and in air conditioning

YY Control Cables -KU4500 – PVC / PUR – Number Coded Cores

These Cables offer increased durability under harsh conditions thanks to a robust PUR outer sheath ensuring the cable is resistant to contact with many mineral oil based lubricants, diluted acids, aqueous alkaline solutions and other chemical media. Commonly used on machine tools , industrial machinery , measurement, control and electrical applications. Outdoor use is possible within the indicated operating temperature range.

YY Control Cables -KU550 – Robust Applications – Number Coded Cores

These Cables offer increased durability under harsh conditions thanks to a special TM2 compound , these cables conform to CEI20-22/II IEC60332 Cat A for fire behaviour , IEC60754 CEI EN50267-2 Halogen emissions , IEC CEI EN 60811-2-1 Industrial Oil Resistance , IEC CEI EN 60811-1-3 Water Absorption. They show good flexibility which makes them easy to install and the materials used makes them perfect for damp & wet environments.

YY Control Cables – KU910 – TPE / TPO – Colour Coded Cores

These Cables offer Enhanced durability under harsh conditions thanks to a robust TPE outer sheath ensuring the cable is resistant to contact with many mineral oil based lubricants, diluted acids, aqueous alkaline solutions and other chemical media. Commonly used on machine tools , industrial machinery , measurement, control and electrical applications. Outdoor use is possible within the indicated operating temperature range of -50 c

Screened Cables

CY Control Cables -KU500C – PVC / PVC – Number Coded Cores

These screened cables are suitable for flexible use in applications of medium mechanical stresses with free movement, without tensile stress or forced movement in dry & moist conditions but not suitable for open air. Used as measuring and control cables in tool machines, conveyor belts, production lines, machinery production and in air conditioning

CY Control Cables – KU4500C – PVC / PUR – Number Coded Cores

These screened cables offer increased durability under harsh conditions thanks to a robust PUR outer sheath ensuring the cable is
resistant to contact with many mineral oil based lubricants, diluted acids, aqueous alkaline solutions and other chemical media. Commonly used on machine tools , industrial machinery , measurement, control and electrical applications. Outdoor use is possible within the indicated operating temperature range.

CY Control Cables  Atex  – KU500C ATEX – PVC / PVC – Number Coded Cores

These screened cables offer increased durability under harsh conditions thanks to an enhanced oil resistant sheath and non fire propagation materials to CEI20-22/II & IEC60332 Cat A , Resistance to oil IEC CEI EN 60811-2-1 and water absorption to IEC CEI EN 60811-1-3. The cable has a blue outer sheath making it suitable to intrinsically safe circuits.

CY Control Cables -KU550C – Robust Applications – Number Coded Cores

These Cables offer increased durability under harsh conditions thanks to a special TM2 compound , these cables conform to CEI20-22/II IEC60332 Cat A for fire behaviour , IEC60754 CEI EN50267-2 Halogen emissions , IEC CEI EN 60811-2-1 Industrial Oil Resistance , IEC CEI EN 60811-1-3 Water Absorption. They show good flexibility which makes them easy to install and the materials used makes them perfect for damp & wet environments.

CY Control Cables – KU910C – TPE / TPO – Colour Coded Cores

These Screened Cables offer Enhanced durability under harsh conditions thanks to a robust TPE outer sheath ensuring the cable is resistant to contact with many mineral oil based lubricants, diluted acids, aqueous alkaline solutions and other chemical media. Commonly used on machine tools , industrial machinery , measurement, control and electrical applications. Outdoor use is possible within the indicated operating temperature range of -50 c

SY Control Cables -KU600 – PVC / PVC – Number Coded Cores

These cables with a GSWB ( Galvanised Steel Wire Braid) offer increased mechanical protection and are suitable for flexible or static use in applications of medium mechanical stresses with free movement, without tensile stress or forced movement in dry & moist conditions but not suitable for open air. Used as measuring and control cables in tool machines, conveyor belts, production lines, machinery production and in air conditioning
