Electronic & Data Cables

Electronic data cables , liyy , liycy, liyy-tp, liycy-tp, par-tronic, UL2464 , UL2516 , Din47100 colour coding available from Contact Cables Ltd

Content for these Cables has been moved HERE

Category:
Click to request data sheet

Description

Unscreened Electronic data Cables

LIYY Flexible Data Cable Din 47100 Ce Approved

These PVC cables are used for flexible use with free movement, without tensile stress or forced movements in dry and wet rooms but not suitable for open air, wherever the construction requirements call for a minimum outer diameter, Tronic is suitable cable to use.This applies especially to such areas as tool making and machine industries as well as electronic , computer , measurement and control sectors. 0.14mm – 1.5mm

LIYY Flexible UL/CSA Cable UL2464 Style 300V

These cables are suitable for use as command, measuring and control cables in tool making ,machinery,conveyor systems and production lines. 26AWG – 16 AWG.

LIYY Flexible UL/cUL Cable UL21179 Style 300V

These KU1510 Cables are suitable for use as command, measuring & control cables, for machine tools, assembly lines and connections between measuring devices and data processing centre of industrial machinery.

LIYY Flexible UL/CSA Cable UL2516 Style 600V

These cables are suitable for use as command , measuring and control cables in tool making , machinery,conveyor systems and production lines. 14 AWG- 12AWG

LIYY-TP UL Twisted Pair UL2464 Style 300V

These twisted pair cables are suitable for use as command and measuring cables in tool making,machinery,conveyor systems and production lines, industrial plants and air conditioning as well as in the steel production industries.
26AWG – 20 AWG

Screened Electronic Cables

Tronic CY ( LIYCY) Flexible Cu Screened Cable Din 47100 Ce Approved

These screened cables are used for flexible use with free movement,without tensile stress or forced movements in dry and wet rooms but not suitable for open air. Where ever the construction requirements call for a minimum outer diameter Tronic CY (LIYCY) is the cable to use. 0.14mm – 1.5mm

LIYCY UL/CSA Flexible Cu Screened Cable UL Style 2464/300V (80ºC) Emc Prefered

This cable is suitable for use as a flexible connector cable in the fields of electronics,control and command technology as well as measuring,signal and impulse transfer. 26AWG- 16AWG

LIYCY UL/CSA Flexible Cu Screened Cable UL Style 2516/600V (105ºC) Emc Prefered

This cable is suitable for use as a flexible connector cable in the fields of electronics,control and command technology as well as measuring , signal and impulse transfer. 14AWG- 12AWG.

Paar-Tronic Paired Flexible Foil Screen Cable Din 47100 Ce Approved

These data cables are used for flexible use with free movement without tensile stress or forced movements.Paar-Tronic is the prefered cable for use in areas where a small diameter is essential to complete wiring. Used as a control and signal cable for measuring instruments , computers and signal transfer. This cable is only suitable for low load applications. 0.14mm- 0.75mm.

Paar-Tronic CY Twisted Pair Flexible Cu Cable Din 47100 Ce Approved

Paar-Tronic CY is well suited for use in areas subjected to signal interference.The high level of screening reduces substantially the effects of electrical distrubances from parellel running wiring.The copper screening is also often used as an “earth”. The twisted pairs conform favourable cross talk attenuation values. 0.14mm – 1.5mm.

Paar-Tronic CY-CY (LIYCY-CY)

Paar-Tronic CY-CY is the perfect cable for use in areas where a small diameter is essential to complete wiring , as a control and signal cable in measuring instruments,computers, process control, security systems and signal transfer. The copper screening assures a distrubance-free data and signal transmission. 0.14mm – 0.5mm.
